AMSOIL Synthetic 10W-40 and
20W-50 Motorcycle Oils
AMSOIL
synthetic 10W-40 and 20W-50 motorcycle oils give motorcyclists
what they need: superior wear protection for high-stress
motocycle engines and transmissions, as well as clutches
that stay clean and deposit-free.
- Runs cooler - reduces crankcase
temperature.
- Superior 12+ TBN synthetic formulation
provides long service life and mximum protection
against engine wear.
- Wet clutch compatible.
- Recommended for all V-twin and
other motorcycle engines requiring an API CD, JASO
MA, SG-CG or SH-CD oil.
Wear Protection
How do other motorcycle oils compare
to AMSOIL Synthetic Motorcycle Oils in wear protection?
ANTI-WEAR
CHEMISTRY
Spectrographic
Analysis: Zinc and Phosphorus
|
Zinc
ppm |
Phosphorus
ppm |
|
AMSOIL 20W-50 |
1336 |
1160 |
AMSOIL 10W-40 |
1357 |
1174 |
Belray EXL 20W-50 |
1183 |
962 |
Harley-Davidson
20W-50 |
1129 |
911 |
Mobil 1 20W-50 |
1218 |
1017 |
Motul 300V Competition
15W-50 |
1196 |
1075 |
Castrol 20W-60 |
1133 |
998 |
|
Optimal
quantities of zinc and phosphorus are
essential to wear protection and top performance
|
|
AMSOIL submitted five popular motorcycle
oils to spectrographic analysis and Four-Ball Wear
(ASTM D4172) testing and compared the results to those
of AMSOIL Synthetic 20W-50 and Synthetic 10W-40 Motorcycle
Oils. None of the popular motorcycle oils compared
favorably to the AMSOIL products in wear additive
content or wear protection (see Spectrographic Analysis
chart and Wear Protection graph). As seen in the chart,
AMSOIL Synthetic Motorcycle Oils contain significantly
higher levels of zinc and phosphorus than the competing
oils, and while simply adding more zinc and phosphorus
doesnt insure good performance, AMSOIL has formulated
motorcycle oils with the best additives in the optimal
quantities to provide superior wear protection.
What about oil temperature and wear?
A Four-Ball Wear Test was con-ducted at 302°F/150°C,
a higher temperature that would typically be associated
with motorcycle oil operating temperatures in extreme
high performance situations. AMSOIL products protect
better in higher temperatures than any of the tested
motorcycle oils do, leaving a wear scar up to 37 percent
smaller. Some motorcycle transmissions and engines
share a common oil sump; so the engine oil must also
provide wear protection to the transmission gears,
which, according to Motorcycle Consumer News (Aug.
1998) are subject to high gear surface pressures and
gear rotation speeds. The superior performance of
the AMSOIL Motorcycle Oils in the Four-Ball Wear Test
applies here, too. Motorcyclists will find no better
oils than AMSOIL Synthetic Motorcycle Oils.
|
|
|
|
|
|
|
Hi-Performance
10W-30 Motorcycle Engine Oil
Superior
synthetic forumation provides long
service life and maximum protection
against engine wear. Superior shear
stability provides unsurpassed protection
for high performance engines and transmissions.
No friction modifiers. Wet clutch
compatible.
Product
Code: MCT |
|
|
|
|
|
|
Hi-Performance
10W-40 Motorcycle Engine Oil
AMSOIL Synthetic
High Performance 10W-40 Motorcycle
Engine Oil is specially formulated
to provide tough lubricating protection
in the most demanding operations.
It is recommended for use in all four-cycle
motorcycle and ATV engines, including
those with wet clutch systems requiring
API CD, SG-CG or SH-CD oils.
Product
Code: MCF |
|
|
|
|
|
|
Hi-Performance
20W-50 Motorcycle Engine Oil
AMSOIL Synthetic
High Performance 20W-50 Motorcycle
Engine Oil is specially formulated
to provide tough lubricating protection
in the most demanding operations.
It is recommended for use in all four-cycle
motorcycle and ATV engines, including
those with wet clutch systems requiring
API CD, SG-CG or SH-CD oils.
Product
Code: MCV |
|
|
|
|
|
|
|
|
AMSOIL Formula 4-Stroke Synthetic
Motor Oil
AMSOIL Formula
4-Stroke Synthetic Motor Oil is specially formulated
to provide serious protection in recreational four-stroke
engines. AMSOIL 4-Stroke virtually eliminates wear
and keeps heat and emissions to an abolute minimum.
Formulated
with a broad 0W-40 viscosity range, AMSOIL Formula
4-Stroke delivers unsurpassed protection and performance
year round, in both hot and cold temperature extremes.
As an SAE 40 weight motor oil, it protects hot operating,
hard working four-stroke motors, while its SAE 0W
rating provides excellent cold weather starting and
quick post-startup lubrication in the coldest temperatures.
AMSOIL Formula 4-Stroke Synthetic
Motor Oil contains a robust dispersant/detergent package
ideal for high-stress four-stroke engines. Formula
4-Stroke is formulated for extended drains, maintaining
its 0W-40 viscosity grade throughout its service life
and providing long-term protection against equipment
wear.
AMSOIL Formula 4-Stroke Synthetic
Motor Oil is formulated without friction modifiers,
ensuring dependable starting, smooth running, improved
fuel efficiency, desirable stall speeds and clutch
compatibility.
The high temperature operation of
four-stroke engines often causes conventional four-stroke
motor oils to volatize and thicken, contributing to
poor oil circulation, reduction in fuel efficiency,
excessive emissions and increased wear. The superior
volatization and thickening resistance of AMSOIL Formula
4-Stroke Synthetic Motor Oil, however, keeps engine
wear, oil consumption and emissions to a minimum while
keeping oil circulation efficient and fuel economy
high.
High
temperature operations also lead to the thermal degradation
and oxidation of conventional oils, forming deposits,
sludge and varnish. The superior oxidative and thermal
stability of AMSOIL Formula 4-Stroke Synthetic Motor
Oil inhibits the formation of varnish, deposits and
sludge so equipment runs clean in the high-stress,
high temperature conditions common to four-stroke
engines.
AMSOIL Formula 4-Stroke Synthetic
Motor Oil provides second-to-none protection and performance
in Yamaha®, Suzuki®, Honda®, Mercury®,
Kawasaki®, Arctic Cat®, Polaris®, Nissan®
and Bombardier® motors and transmissions specifying
0W-40, 5W-30, 10W-30 and 10W-40 viscosity grades.
AMSOIL Formula 4-Stroke Synthetic Motor Oil is also
safe for use in wet or dry sumps and is recommended
for manual or automatic clutches and with clutch plates.
|
|
|
|
|
|
|
Formula
4-Stroke® Power Sports Synthetic Motor
Oil
AMSOIL Formula
4-Stroke® Power Sports 0W-40 Synthetic
Motor Oil is specially formulated
for ATVs, snowmobiles and other power
sports applications. Its broad viscosity
range and wax-free formulation make
it excellent for use in both hot and
cold temperature extremes.
Product
Code: AFF |
|
|
|
|
|
|
Formula
4-Stroke® 10W-40 Synthetic Scooter
Oil
AMSOIL Formula
4-Stroke® 10W-40 Synthetic Scooter
Oil (ASO) is formulated specifically
to meet the special needs of today’s
high-tech air- and water-cooled fourstroke
motorized scooters, offering unsurpassed
wear protection and friction reduction
for longer equipment life and cooler
operating temperatures.
Product
Code: aso |
|
|
|
|
|
|
|
|
AMSOIL Engine Fogging Oil
Two- and four-stroke recreational
vehicles, hand held power equipment, small engines,
construction and farm equipment are commonly operated
seasonally or infrequently, then stored for long periods
of time. During these periods of inactivity, and as
a result of fluctuations in ambient temperatures,
water vapor can form condensate within the engine.
When this condensate comes into direct contact with
steel and iron components, it forms surface corrosion
on cylinder liners, piston rings, anti-friction bearings
and steel/iron contact surfaces on rotational seals.
Long periods of storage can also dry out cylinders,
often resulting in permanent damage when the equipment
is taken out of storage and dry started.
New AMSOIL Engine Fogging Oil offers
superior film retention, providing long-term protection
against corrosion and dry starts, extending engine
life and reducing operating expenses. Its aerosol
spray formulation offers easy and clean applications,
while reaching more components and offering better
distribution than straight motor oil.
AMSOIL Engine Fogging Oil applications
include, but are not limited to, motorcycles, snowmobiles,
ATVs, outboard motors, stern drive and inboard
marine engines, personal watercraft, lawn equipment,
chainsaws, snowblowers, portable generators, hand
held power equipment, motor scooters, powered farm
equipment, powered construction equipment, cars and
trucks.
|
|
|
|
|
|
|
AMSOIL
Engine Fogging Oil
Offers superior
film retention, providing long-term
protection against corrosion and dry
starts, extending engine life and
reducing operating expenses. Its aerosol
spray formulation offers easy and
clean applications, while reaching
more components and offering better
distribution than straight motor oil.
Product
Code: FOG |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
